GAO822
HIGH TRACTION FOR OFF-ROAD USAGE ▪ DURABILITY & EXTENDED SERVICE LIFE
All Position
All Position
16 - 24
Rim Size
0 - 95
Aspect Ratio
11 - 325
Section Width
-
Speed Rating
Features
- Aggressive block pattern and open shoulder design
- Deep tread pattern design
- Tie-bar design between center blocks
- Reinforced casing and bead structure
- Specially formulated tread compound
- Thickened base rubber
Benefits
- Provides high traction, with self-cleaning performance
- Provides longer tire service life
- Effectively prevents pattern blocks from tearing
- Improves durability of casing and bead, and increasing tire damage resistance in heavy load operating conditions
- Provides strong cut and chip resistance on tough off road conditions
- Protects groove bottom from tearing and puncturing
| Tire Size | PR | Load Index | Speed Rating | Approved Rim | Outer Diameter (mm) | Tread Depth (mm) | Max Load (kg) | Max Pressure | |
| kPA | PSI | ||||||||
| 10.00R20 | 18 | 149/146 | F | 7.5 | 1054 | 22.6 | 3250/3000 | 930/930 | 135/135 |
| 11.00R20 | 18 | 152/149 | F | 8 | 1096 | 23.5 | 3550/3250 | 930/930 | 135/135 |
| 12.00R20 | 20 | 156/153 | F | 8.50 | 1136 | 24.5 | 4000/3650 | 900/900 | 130/130 |
| 325/95R24 | 22 | 162/160 | G | 9 | 1228 | 26 | 4750/4500 | 850/850 | 123/123 |
| Tire Size | LI | SI |
| 10.00R20 | 149/146 | F |
| 11.00R20 | 152/149 | F |
| 12.00R20 | 156/153 | F |
| 325/95R24 | 162/160 | G |
